Type:Logic ICs
Condition:New
1 , all the components of the finished board includes on-board components are all brand new , no used , disassemble components, namely, the resulting picture . Imported high-quality solder wire welding, prior to shipment are powered by audition and buy with confidence .
2, LME49810 push three pairsON audio power transistorNJW0281G / NJW0302G,,Two-channel amplifier board , 30-300 watts per channel output (depending on voltage) .
Use6 pairs of newPairing audio power transistor ONNJW0281G / NJW0302G(250V15A150W), every channel uses three pairs of parallel , the total output current up to 45A, control, powerful thrust . Power tube bolt hole because debugging a slight indentation, but retain the original foot ( no longer part of the cut ) , after users receive their own cut is .
The plate material excellent , according to their listening habits repeatedly tuning.
Using C4495 for WC4883/A1859For promoting the tube .
Other Ingredients:Resistance ,4.7 input capacitance ,Adjustable potentiometer,silver electrolysisFeedback , 100v pressure electrolysis.
3 , recommended voltage : DC35 -80v.
Description: This boardWhen voltage 70-80v work on the 8 ohm impedance output power up to 300W or more effective .
4 , printed board size : 194 * 58mm 2mm thick FR4 material 70um thick copper
Finished board size : 194 * 80mm ( with power tube width ) .
